B24-005 | Commingled glass fabric with PA6 – 520 g/m2

SKU: B24-005 Category:
  • Tax not included.
  • For a diferente width or grammage, please contact us.
  • Price €/m2: 8,65€

5,00 432,30  Tax not included

The B23-002 TAP-CF/BIOPA-16MM-PL-300 is a high-performance bidirectional fabric that combines 16mm carbon tapes with a bio-based polyamide matrix. This fabric is engineered for high-demand applications, providing excellent flexibility and ease of handling.

Properties:

  • Fiber Areal Weight (FAW): 150 g/m²
  • Weight per Ply (PAW): 300 g/m²
  • Resin Content by Weight: 50% BIOPA
  • Moisture Pick Up: 0.8% (Kept in water for 28 days at 23ºC)
  • Consolidated Ply Thickness (CPT): 0.16 mm

Fabric Design:

  • Fiber Type: Carbon Fiber
  • Pattern: Plain
  • Tape Width: 16 mm
  • Fabric Width: 100 up to 200 cm (Contact us for special widths)
  • Density: 0.6 picks/cm

Typical Neat Resin Properties:

  • Density: 1.13 g/cm³
  • Tg: 63ºC
  • Tm (Melt): 215ºC
  • Tp (Processing): 260ºC

Main Features:

  • Flexible
  • Recyclable
  • Short time processing
  • Easy to manipulate and cut
  • Can be stored at room temperature

Typical Applications:

  • Sports goods
  • Automotive industry
  • Renewable power sector
