THERMOPLASTIC PREPREGS COLLECTION
COMMINGLED
Hybrid or commingled fabrics combine pre-blended fibers and matrix material for a more uniform distribution, improving
interfacial bonding and mechanical properties. They have short processing times, high flexibility, and enable customization
of fiber-matrix combinations.
| CODE | REFERENCE | COMPOSITION | FABRIC CONSTRUCTION | WEIGHT | MATRIX CONTENT BY WEIGHT | DATA SHEET | SHOP |
|---|---|---|---|---|---|---|---|
| B24-011 | COM-3KCF/PC-300T-TW-300 | CF/PC | TWILL 2/2 | 300 | 36% |  |  |
| B24-012 | COM-3KCF/PP-300T-TW-300 | CF/PP | TWILL 2/2 | 300 | 28% | |  |
| B24-009 | COM-12KCF/PP-1195T-TW-574 | CF/PP | TWILL 2/2 | 574 | 36% | | |
| B00-018 | COM-RY/PP-1576T-TW-450 | RT/PP | TWILL 2/2 | 450 | 38% | | |
| B00-014 | COM-GF/PP-1800T-TW-500 | GF/PP | TWILL 2/2 | 500 | 67% | | |
| B24-005 | COM-GF/PA6B-1855T-TW-520 | GF/PA6 | TWILL 2/2 | 520 | 33% | | |
| B24-006 | COM-GF/PA6B-1855T-PL-520 | GF/PA6 | PLAIN | 520 | 33% | | |
| B24-010 | COM-GF/PA6W-470-PL-565 | GF/PA6 | PLAIN | 565 | 67% | | |
| B24-001 | COM-GF/PAGB-450T-TW-650 | GF/PA6 | TWILL 2/2 | 650 | 67% | | |
| B24-003 | COM-GF/PA6W-400T-PL-300 | GF/PA6 | PLAIN | 700 | 67% | | |
| B00-016 | COM-3KCF/PET-400T-TW-500 | CF/PET | TWILL 2/2 | 500 | 34% | | |
| B00-015 | COM-GF/PET-596T-TW-550 | GF/PET | TWILL 2/2 | 550 | 36% | | |
- *Roll width from 100 cm up to 200 cm.
- *Roll length from 50 m up to 100 m.
CODE
COMP.
WEIGHT
+INFO
- REFERENCE: COM-3KCF/PP-300T-TW-300
- FABRIC CONSTRUCTION: TWILL 2/2
- REFERENCE: COM-12KCF/PP-1195T-TW-574
- FABRIC CONSTRUCTION: TWILL 2/2
- REFERENCE: COM-TY/PP-1576T-TW-450
- FABRIC CONSTRUCTION: TWILL 2/2
- REFERENCE: COM-GF/PP-1800T-TW-500
- FABRIC CONSTRUCTION: TWILL 2/2
- REFERENCE: COM-GF/PA6B-1855T-TW-520
- FABRIC CONSTRUCTION: TWILL 2/2
- REFERENCE: COM-GF/PA6B-1855T-PL-520
- FABRIC CONSTRUCTION: PLAIN
- REFERENCE: COM-GF/PA6W-470-PL-565
- FABRIC CONSTRUCTION: PLAIN
- REFERENCE: COM-GF/PAGB-450T-TW-650
- FABRIC CONSTRUCTION: TWILL 2/2
- REFERENCE: COM-gf/PA6W-400T-PL-700
- FABRIC CONSTRUCTION: PLAIN
- REFERENCE: COM-3KCF/PET-400T-TW-500
- FABRIC CONSTRUCTION: TWILL 2/2
- REFERENCE: COM-GF/PET-596T-TW-550
- FABRIC CONSTRUCTION: TWILL 2/2
- *Roll width from 100 cm up to 200 cm.
- *Roll length from 50 m up to 100 m.
THERMOPLASTIC PREPREGS COLLECTION
OTHER PRODUCTS
DRY FABRICS
Bidirectional resin-free fabrics compatible for thermoset and thermoplastic composites. Blackfabric specializes in carbon fiber but also weaves other materials.
EXPLORE THE ELEGANCE OF SPREAD-TOW TAPES FABRICS
Wide tapes impregnated with thermoplastic polymers, enhancing high strength, great impregnation, and smooth surface finish.
Blackfabric develops and produces customized fabrics for technical applications
Feel free to contact us, we’ll be very happy to help you to find a solution.
